Petro-Chemical Industry Magnets

Drawer-In-Housing

Drawer-In-Housing

Our Drawer-In-Housing magnetic separators, also known as Drawer Magnets or Grate In Housings, consist of rows of round magnetic tubes that are assembled into drawers contained inside of a housing.

Learn More About Drawer-In-Housing
Large Tube Housing®

Large Tube Housing®

IMI's new LTH (Large Tube Housing) incorporates 3" diameter rare earth tubes into our proven Drawer-in-Housing configuration.

Learn More About Large Tube Housing®
Bullet® Magnet

Bullet® Magnet

Aerodynamically shaped with a solid stainless steel nose cone diverter, the flow-thru design of the Bullet® Magnet maintains uniform velocity in line flow, allowing it to be used anywhere in the pneumatic system.

Learn More About Bullet® Magnet
Plate Style T-Trap

Plate Style T-Trap

When tramp metal protection is required for liquid lines carrying viscous to fibrous products, such as meats, fruit preserves, cheeses and sinewy items, the plate style T-Trap is ideal. This magnet allows the product to flow through the housing without causing product bridging.

Learn More About Plate Style T-Trap
Tube Style T-Trap

Tube Style T-Trap

Industrial Magnetics' T-Trap Magnetic separators are designed for heavy duty, large volume liquid and semi-liquid line flow systems.

Learn More About Tube Style T-Trap
Magnetic Grates

Magnetic Grates

Magnetic Grate Separators, also known as grate magnets or hopper magnets, deliver ferrous tramp metal separation in bins, chutes, drawers, hoppers and circular enclosures. We offer both ceramic and rare earth grate magnets.

Learn More About Magnetic Grates
4JIT Vacuum Line Magnet

4JIT Vacuum Line Magnet

In vacuum systems, located between the gaylord and the vacuum loader, the Vacuum 4JIT magnet captures ferrous tramp contaminates. The powerful Rare Earth Vacuum 4JITline magnet provides equipment protection and improved product purity without restricting resin flow.

Learn More About 4JIT Vacuum Line Magnet
Granulator Plate Magnet

Granulator Plate Magnet

Protect your plastic regrind operation from tramp metal contamination with IMI's powerful Granulator Plate Magnets.

Learn More About Granulator Plate Magnet
4JIT Bullet® Magnet

4JIT Bullet® Magnet

The 4JIT Bullet® can be used anywhere in a pneumatic system. It is ideal for dilute phase pneumatic systems, typical applications include processing of dry, powder and granular materials. Use ahead of processing equipment to protect machinery from tramp metal damage and at bulk load out zones to ensure product purity.
