Mag-Mate > Lifts > VersaLift™ Magnets
VersaLift™ Lifting Magnets with Test Mode, Horizontal & Vertical Lifting Capability and RFID Chip
Compact and powerful Rare Earth lift magnet for use on flat or round surfaces. Contains an internal ON/OFF release device that does not contact or damage the surface of the part. More features than other lifts and manufactured in the USA (USA M.A.D.E.™).
- Rare Earth Magnet with a Locking On/Off handle & Test load feature
- Supports custom pole shoes
- Lifts flat or round loads (see chart below)
- Heat resistant up to 180°F (82°C)
- Stationary Lift Lug(s)
- Vertical Lift Capability using the optional Lift Lug attachment
- RFID tagged
- 3:1 Design Factor
- CONFORMS TO ASME B30.20 STANDARDS
Test Load Feature
To operate Test Feature, pull spring loaded handle out and rotate it to the “TEST” position. Lift load approximately 2-3” to verify the magnet has the capacity to lift your load. Once verified, place load back down and turn the handle to the “ON” position. Never complete entire lift operation in “TEST” position.
Download Product Page
Order Online - click the part number to add to shopping cart
| Rare Earth VersaLift™ Magnets |
| |
Lift |
Overall |
Magnet |
Handle |
Bail |
Lift Lug Adaptor |
| Shipping |
Model No. |
LBS |
KG |
Ht. (in) |
Ln. (in) |
Ht. (in) |
Wd. (in) |
Ln. (in) |
Wt. (lbs) |
Ln. (in) |
Th. (in) |
Ht. (in) |
Wd. (in) |
Part No. |
Ln. (in) |
Wt. (lbs) |
 |
VL0275 |
275 |
124 |
6-1/2 |
5 |
3-3/4 |
5 |
3-5/8 |
10 |
6 |
3/4 |
2-1/4 |
1-3/4 |
VLLUG1 |
4-1/2 |
3 |
|
VL0600 |
600 |
272 |
6-1/2 |
7 |
3-3/4 |
5 |
5-5/8 |
18 |
6 |
3/4 |
2-1/4 |
1-3/4 |
VLLUG1 |
4-1/2 |
3 |
|
VL1200 |
1200 |
544 |
6-1/2 |
11 |
3-3/4 |
5 |
10 |
34 |
6 |
3/4 |
2-1/4 |
1-3/4 |
VLLUG1 |
4-1/2 |
3 |
|
VL2500 |
2500 |
1134 |
10-1/2 |
14-1/2 |
5-1/2 |
7 |
13 |
119 |
8-3/4 |
3/4 |
2-1/4 |
1-3/4 |
VLLUG2 |
4-1/2 |
3 |
| Lifting Value in lbs (kg) & *Maximum Sheet Length Due To Sag For Material Thickness For Single Magnet Use |
| Model No. |
1/4" (6' Lg) |
3/8" (8' Lg) |
1/2" (8' Lg) |
3/4" (8' Lg) |
1" (10' Lg) |
2" (10' Lg) |
3" (10' Lg) |
| VL0275 |
150 (68) |
220 (99) |
240 (108) |
250 (113) |
275 (124) |
275 (124) |
275 (124) |
| VL0600 |
260 (117) |
435 (197) |
525 (238) |
550 (249) |
600 (272) |
600 (272) |
600 (272) |
| VL1200 |
NA |
755 (342) |
960 (435) |
1165 (528) |
1200 (544) |
1200 (544) |
1200 (544) |
| VL2500 |
NA |
NA |
NA |
1700 (771) |
1800 (816) |
2500 (1134) |
2500 (1134) |
| NOTE: Holding Values for the VersaLift™ Magnets are stated at 33% of the actual value. We recommend when lifting sheets over 8’, use 2 or more lifts on a spreader bar to prevent sheet flexing, sagging or peel-off. Thin material is susceptible to magnetic bleed through, resulting in two sheets being lifted at once. Round Holding Values are based on ideal conditions. Consult the factory before specifying these magnets for use on round materials. *Max. sheet lengths are selected due to sag characteristics of specified sheet. The item to be lifted must cover the entire length and width of the magnetic poles to properly engage and release the part. CF = Consult Factory, NA = Not Applicable (Magnets will not turn “ON” with stated thicknesses.) |
| |
Round Lifting Applications |
Vertical Lift (Flat Only) |
| Model No. |
Max. Lift - lbs (kg) |
Max. Lift at Min. |
Min. Diameter / Thickness |
Lift - lbs (kg) |
Min. Thickness |
| VL0275 |
137 (49) |
50 (22) |
2.00 In. / 0.12 In. |
68 (30) |
1.00 In. |
| VL0600 |
300 (136) |
130 (58) |
2.00 In. / 0.12 In. |
150 (68) |
1.00 In. |
| VL1200 |
600 (272) |
600 (272) |
4.00 In. / 0.50 In. |
300 (136) |
1.00 In. |
| VL2500 |
1250 (567) |
1250 (567) |
8.00 In. / 1.00 In. |
625 (283) |
3.00 In. |
|
 |
